Functional Diagnostics
ri-scope F.O. Nasal Speculum
Riester · 10575
Article No. AK-FD-454
The ri-scope F.O. nasal speculum is a handheld diagnostic instrument specifically designed for the safe and precise examination of the nasal passage. The integrated fibre optics with 3.5 V LED illumination ensures optimal light transmission and focusing, producing a cool examination light similar to daylight. This significantly contributes to improved visualisation of anatomical structures and increases diagnostic safety. The speculum features a swivelling and removable lens with 2.5x magnification, enabling detailed inspection without loss of focus. Controlled spreading of the speculum is achieved via a screw adjuster, while rapid spreading is possible by simply pressing down the adjuster. This operating concept supports a gentle and individually adaptable examination of the patient. Another advantage is the shock-resistant housing made of glass fibre reinforced plastic, which ensures high durability and reliability in daily work in a medical practice. Compatibility with the ri-scope L handle and the ri-former diagnostic station with theft protection provides flexibility and security when integrating into existing diagnostic systems. Thanks to modern lighting technology and high-q
Specifications
- Brand
- Riester
- Model
- 10575
- Product type
- Pen Torches Diagnostic Lights
- Average LED lifespan
- up to 100,000 hours
- Bayonet fitting diameter
- 22 mm
- Dimensions
- 71 x 68 mm
- Temperature
- 0 °C to 40 °C
- Relative humidity
- 30% to 70%, non-condensing
- Air pressure
- 800 hPa to 1100 hPa
- Power supply
- Various options (depending on handle/station)
- Light source
- LED fibre optics, 3.5 V, 300 mA
- Magnification
- 2.5x (swivelling and removable lens)
- Housing material
- Glass fibre reinforced plastic, shock-resistant
