SONY UP-DR80MD A4 Digital Colour Printer
Sony Corporation · UP-DR80MD
Article No. AK-IR-105
The compact SONY UP-DR80MD digital colour printer features outstanding image quality and particularly low running costs. With the help of the printer driver programme supplied and a display of a preview image, colour matching can be carried out without complications. In addition, two colour tables ensure matching colour reproduction in various applications such as endoscopy and ultrasound examinations. Thanks to the innovative lamination technology, the prints of the SONY printer are resistant to heat and light as well as protected against water and fingerprints. Long-term storage of printouts is therefore possible without any signs of deterioration. The high-speed printing ensures A4-size image prints within approx. 76 seconds. Prints two paper sizes: A4 (297 x 210 mm) & Letter (279 x 216 mm) UPA-WU10 wireless and optional printing system for a wireless connection between printer and devices Dimensions: approx. 317 x 425 x 207 mm (W x D x H) Picture elements: A4 format: 2.392 dots × 3.400 dots; Letter format: 2.464 dots × 3.192 dots
Specifications
- Brand
- Sony Corporation
- Model
- UP-DR80MD
- Product type
- Video Printer Paper Printers
- Optional
- ribbon/paper roll, self-laminating colour print set, UPC-R80MD
- Power supply
- 100V - 240 V alternating voltage, 50/60 Hz
- Input current
- 3.4 to 1.4 A
- Operating pressure
- 700 hPa to 1060 hPA
- Weight
- approx. 11.5 kg
- Printing system
- Dye sublimation printing on thermal transfer basis
- Thermal printhead
- 11.83 dots/mm, 2,560 dots (301 dpi)
- Gradation
- 8-but processing (256 levels) each for yellow , magenta and cyan
- Printing time
- approx. 76 seconds (A4 format); approx. 72 seconds (letter format)
- Interface
- Hi-Speed USB (USB 2.0)
