Hospital Furniture
Fold Down Exam Table 125-04/L+64-149
125-04/L+64-149
Article No. AK-HF-302Product details
- Article number
- AK-HF-302
- Category
- Hospital Furniture
- Brand
- AKLION
- Model
- 125-04/L+64-149
Description
The space-saving wall-mounted fold down exam table from Dewert has a two-part lying surface and a head section that can be adjusted by up to 30°. The table was specially designed to be mounted on one side of a stable stone wall and can be folded upwards on the long side if required. When folded up, the couch can be fixed in place with the help of the safety holder with strap. Folding out is simplified by the gas spring-supported foot release. The particularly robust table frame consists of a stable square tube and allows a maximum load capacity of up to 200 kg. In addition, the lounger has galvanised steel hinges that serve as connecting elements between the head and foot sections. The positive headboard adjustment is facilitated by the two parallel safety grids. The smooth upholstery cover with velvety shimmer effect is antibacterial, latex-free and available in many different colours. Material composition: approx. 3 % PVC-PU finish, approx. 12 % BW/PES knitted fabric, approx. 85 % PVC compound Flame retardant (NF M2, BS 5852 IS-0+1, DIN 4102 (Part 1, B2), DIN EN 1021 1+2, MVSS 302)
Request a quotation
Equipment standard by AKLION — configuration, accessories and lead time are confirmed on the quotation.
Technical specifications
- Model
- 125-04/L+64-149
- Product type
- Examination Couches
- Headrest length
- 550 mm
- Footrest length
- 1400 mm
- Upholstery thickness
- 80 mm
- Length of the lying surface
- 1950 mm
- Total length (with wall brackets)
- 2040 mm
- Width of the lying surface
- 650 mm
- Height
- 700 mm
- Weight
- 35 kg
- Max. load capacity
- 200 kg
- Thickness
- 1.35 +/- 0.2 mm
